File:Paschen Config.png
From wwwelab
Size of this preview: 800 × 425 pixels. Other resolution: 320 × 170 pixels.
Original file (1,042 × 554 pixels, file size: 24 KB, MIME type: image/png)
Diagram illustrating the variables from the sweeping signal. The red dots represent data acquisitions. The full line represents the signal generated by the hardware, while the dashed line represents the ideal signal. The smaller the step values are the closer the signal become to the ideal.
